Intelligent operation system; Easy operation with visual and audio alarms; Multi-purpose service/maintenance interface; Profiling: sodium concentration and UF curve;

Main performance of this device:

1. Self-checking function;
2. Carbonate dialysis;
3. Double needle dialysis;
4. Liquid level detector;
5. Bubble detector;
6. Blood leakage detector;
7. Temperature and electric conductivity monitoring;
8. Arterial pressure, venous pressure and transmembrane pressure monitoring;
9. Rolling blood pump;
10. Heparin pump;
11. Dehydration amount controlled by capacity;
12. Automatic disinfection cleaning program;
13. Stand-by power of blood pump in case of power failure;
14. Information display function of display screen.

PS:This device is designed and manufactured in strict accordance with the Requirements of national laws and regulations. The reference standards of design and manufacture are following: GB9706.1-2007; GB9706.2-2003; and YY0054-2003.

Size &Weight:

Size: 380mmx400x1380mm (L*W*H);

Area: 500*520mm;

Weight: 80KG;

Power supply:

AC220V, 50Hz/60Hz, 10A

Input power: 1500W

Back-up battery: 30 minutes

Water input pressure: 0.1Mpa~0.6Mpa, 15P.S.I~60P.S.I

Water input temperature: 5℃~30℃

Working environment temperature: 10℃~30℃ at relative humidity ≦70%

UF rate:

Flow range: 0ml/h~4000ml/h

Resolution ratio: 1ml

Precision: ±30ml/h

Blood pump &Spare pump:

Blood pump flow range: 30ml/min~600ml/min (diameter: 8mm or 6mm)

Spare pump flow range: 30ml/min~600ml/min (diameter 8mm or 6mm)

Resolution ratio: 0.1ml

Precision: ±10ml or 10% of reading

Heparin pump:

Syringe size: 20, 30, 50ml

Flow range: 0ml/h~10ml/h

Resolution ratio: 0.1ml

Precision: ±5%

Venous pressure: -180mmHg ~ +600mmHg, ±10mmHg
Arterial pressure: -380mmHg ~ +400mmHg, ±10mmHg
TMP: -180mmHg ~ +600mmHg, ±20mmHg
Dialysate temperature: preset range 34.0℃~39.0℃
Blood leak detection: Photo chromic alarm when erythrocyte specific volume is 0.32±0.02 or blood leak volume is equal or more than 1ml per liter of dialysate.
Bubble detection: Ultrasonic, Alarm when a single air bubble volume is more than 200μl at 200ml/min blood flow
Conductivity: Acoustic-optic

Disinfection/Sanitize:

1. Hot disinfection:
Time: 30 minutes; Temperature: about 80℃, at flow rate 500ml/min;
2. Chemical disinfection:
Time: 30minutes, Temperature: about 36℃~50℃, at flow rate 500ml/min;
3. Chemical disinfection with heat:
Time: 45minutes, Temperature: about 36℃~80℃, at flow rate 50ml/min;
4. Rinse:
Time: 10minutes, Temperature: about 37℃, at flow rate 800ml/min;
